S450GD Cold Rolled Zn-al-mg Steel Coil American

S450GD Cold Rolled Zn-al-mg Steel Coil American

Size range: 550-960m
Thickness: 0.25-4.0mm
Zinc coating: 20g/m²~400g/m²

Quantity:
Availability:





Inquire Add to Basket

Product Description

S450GD Cold Rolled Zn-Al-Mg Steel Coil Supplier

Product Introduction

Our S450GD Cold Rolled Zn-Al-Mg Steel Coil is designed for superior corrosion resistance and durability, making it ideal for a wide range of applications in construction, automotive, and industrial sectors. The Zn-Al-Mg coating, which consists of zinc, aluminum, and magnesium, provides excellent protection against corrosion and environmental damage.

Key Features

Enhanced Corrosion Resistance: The Zn-Al-Mg coating significantly improves the corrosion resistance compared to traditional galvanized steel coils, making it suitable for harsh environments.
Self-Healing Properties: The coating forms a dense protective film around the cutting surface, which helps to inhibit corrosion and extend the service life of the coils.
Longevity: Due to its strong corrosion resistance and self-healing effect, components made from Zn-Al-Mg coated steel can typically reach over 30 years of service life.
Easy to Process: The coating is dense and does not easily produce coated glass during the stamping process, making it excellent for welding, stretching, stamping, and bending.
Good Scratch Resistance: The surface coating has good scratch resistance, which can greatly avoid scratches during processing.
Weldability: The coils can be welded with reasonable processes and achieve the required strength, without affecting their use.
Lighter Weight: Zn-Al-Mg steel coils provide lighter weight, an advantage that is reflected in applications such as photovoltaic mounts.

Product Details:

Product name	S450GD Cold Rolled Zn-al-mg Steel Coil American
Standard	EN10324, JIS G 3323-2012, ASTM A 1046, etc.
Material thickness	0.25~4.0mm
Material width	550~960mm
Coating weight	20g/m2~400g/m2
The content of aluminum and magnesium are 2 kinds of combinations, which are low aluminum and low magnesium medium aluminum and medium magnesium, that is, 1.5 magnesium 2 aluminum, 3 magnesium 6 aluminum. Surface treatment can be consulted in detail.
Delivery	7-30 days
Payment Method	TT/LC
Port	Tianjin Xingang Port

Mechanical Properties

Proof stress Rp0,2 MPa min.	Tensile strength Rm MPa min.	Elongation at fracture A80 % min.
450	510	14

Applications

Construction: Ideal for structural components, supports, and frames in buildings and infrastructure projects.
Automotive: Suitable for manufacturing parts that require high corrosion resistance and durability.
Industrial: Perfect for various industrial applications where long service life and reliability are crucial.

Packaging and Delivery

Packaging: Standard export packaging, ensuring safe transportation and handling. Each bare coil is securely tied with two bands through the eye of the coil and one circumferential. The contact points of these bands on the coil edge are protected with edge protectors. The coil is then properly wrapped with waterproof paper and completely metal wrapped. Wooden and iron pallets can be used or as per your requirements.
Delivery Time: 3-15 days, depending on the order quantity and destination
